When a Hyster Spacesaver forklift needs more than routine servicing, finding the correct procedure for its engine, transmission, or hydraulic assembly becomes essential. The Hyster C004 S60E, S70E, S80E, S100E and S120E service manual provides workshop reference information for these forklift models, helping you investigate faults, identify components, and prepare repair work with greater precision. Whether you're tracing a fuel-system problem, inspecting the drive axle, or servicing the mast, this manual brings relevant technical information together for workshop use.

Machine Information

Manufacturer	Hyster
Forklift Series	Spacesaver
Series Code	C004
Models Covered	S60E, S70E, S80E, S100E, S120E
Regional Specification	Europe-related model equivalents are listed separately in the service documentation
Equipment Type	Internal-combustion counterbalance forklift
S60E Capacity Class	6,000 lb (approximately 2,722 kg)
S70E Capacity Class	7,000 lb (approximately 3,175 kg)
S80E Capacity Class	8,000 lb (approximately 3,629 kg)
S100E Capacity Class	10,000 lb (approximately 4,536 kg)
S120E Capacity Class	12,000 lb (approximately 5,443 kg)
Powertrain	GM gasoline/LPG and Perkins diesel configurations, depending on the truck
Transmission	Single-speed powershift or two-speed manual transmission, depending on configuration
Typical Applications	Industrial material handling, warehouse work, and heavy-load movement on suitable surfaces

Service Information for Major Components

Engine, Cooling, and Fuel Systems

Use the applicable engine procedures when investigating starting difficulties, engine performance issues, or fuel-delivery faults. The listed manual coverage includes GM engine information, Perkins 4.236 and 4.2482 diesel engines, cooling-system servicing, Rochester carburetor information, and LPG fuel-system procedures. Confirm the engine and fuel system installed on your forklift before following a specific procedure.

Transmission and Drive Axle

When investigating shifting or drivetrain problems, consult the single-speed powershift transmission description, operation, and repair sections. Two-speed manual transmission and drive axle topics are also listed, allowing you to identify the relevant transmission configuration and refer to the corresponding service information.

Hydraulic Pump, Control Valve, and Cylinders

For lifting or tilting issues, refer to the hydraulic pump drive assembly, hydraulic gear pumps, flow control valve, main control valve, tilt cylinders, and lift cylinders. These sections support inspection and repair planning for the components responsible for hydraulic operation and mast movement.

Steering, Brakes, and Electrical Troubleshooting

Use the relevant procedures for the steering control unit, steering axle, master cylinder, and brake system when preparing repairs. Electrical coverage includes alternator and starter information, instrument-panel indicators and senders, electrical warning devices, and electrical-system troubleshooting.

Mast Assemblies and Maintenance

The manual includes upright descriptions and repair procedures, Vista upright operation and repair, periodic maintenance, capacities and specifications, technical diagrams, and inch (SAE) and metric fastener references. These details help you identify the relevant assembly and check service requirements during workshop work.

Manual Specifications

Manual Title	Hyster C004 S60E, S70E, S80E, S100E, S120E Forklift Service Repair Manual
Document Type	Workshop service, repair, and maintenance manual
File Format	PDF digital document
Language	English
Technical Content	Engine, cooling, fuel systems, transmission, drive axle, hydraulics, steering, brakes, electrical systems, and mast repairs
Reference Material	Service procedures, diagrams, specifications, and maintenance information
PDF Use	Digital viewing and printing with compatible PDF software
Compatible Devices	Computer, laptop, tablet, or smartphone with a PDF reader

Confirm Your Model and Series Before Ordering

The C004 S60E, S70E, S80E, S100E, and S120E designations are associated with internal-combustion Spacesaver forklifts despite the letter E in the model names. Check the identification plate, engine type, and transmission configuration before purchasing. If your truck carries a European metric designation such as S3.00E, S3.50E, S4.00E, S5.00E, or S5.50E, verify that the edition you select explicitly covers that model.

Get Your Hyster C004 Service Manual from Manualskart

Keep the relevant workshop information available when your forklift needs inspection or repair. Order the Hyster C004 S60E, S70E, S80E, S100E and S120E PDF Service Manual from Manualskart to support troubleshooting, maintenance planning, and servicing of the covered Spacesaver forklift models.

Frequently Asked Questions

Which Hyster models does this manual cover?

The C004 listing covers the S60E, S70E, S80E, S100E, and S120E Spacesaver forklifts. Confirm the selected edition's coverage if your machine uses a European metric model designation.

Does the manual include gasoline, LPG, and diesel information?

The listed content includes GM engine information, Perkins 4.236 and 4.2482 diesel engine topics, Rochester carburetor information, and LPG fuel-system procedures. Check your installed configuration before using a procedure.

Does the manual cover hydraulic and transmission repairs?

Yes. Listed sections include hydraulic pumps, flow and main control valves, cylinders, drive axle, single-speed powershift transmission, and two-speed manual transmission information.

Are electrical diagrams and mast procedures included?

The listed coverage includes electrical-system troubleshooting, instrument-panel indicators, warning devices, upright repairs, and Vista mast information.
