Case IH Kp-525 Steiger Tiger Tractor Parts Manual PDF

Maintaining the KP-525 Steiger Tiger, one of the most powerful articulated tractors of its era, requires precise technical data to handle its heavy-duty industrial components. This official parts catalog provides the verified OEM part numbers and high-definition exploded views needed to identify, source, and replace parts for the Series IV Tiger, bypassing the need for a dealership's archives.

This manual is structured to provide an exhaustive breakdown of the Tiger’s massive mechanical systems:

• Engine & Fuel: Complete parts listings for the Cummins KTA-1150 (18.8L) 6-cylinder engine, including turbochargers, fuel injection pumps, and cooling system hardware.

• Drivetrain: Detailed schematics for the Allison 6x4 powershift transmission, transfer cases, and heavy-duty outboard planetary axles.

• Hydraulics: Exploded views of the open-center load-sensing system, including high-flow pumps, remote valves, and steering cylinders.

• Chassis & Articulation: Parts for the heavy-duty center oscillation joint, frame components, and the Safari cab interior.

• Electrical: Full routing for wiring harnesses, instrument clusters, and starting system hardware.

The searchable PDF format allows you to pinpoint a specific seal or bearing while standing at the machine. You can zoom in on intricate gear assemblies on your smartphone or print out hard copies for the workshop to keep your digital devices grease-free. Your download link is delivered immediately after a secure checkout, ensuring you have the factory data needed to keep this legendary 525-horsepower machine in the field.
