Bobcat WB700 Walk-Behind Mower Parts Catalog (PDF)

Bobcat WB700 Walk-Behind Mower | Parts Catalog

Maintaining a commercial walk-behind like the Bobcat WB700 is all about protecting that surgical cutting precision. When you’re dealing with a machine built for tight spaces and all-day use, having the right part numbers on hand is the difference between a quick fix and a week of downtime. This digital catalog is designed to be your primary tool for managing those repairs without the guesswork.

What’s Inside This Guide

Instead of digging through generic charts, this manual uses high-resolution exploded views to show you exactly how your mower goes together. It covers everything from the Kawasaki engine components to the heavy-duty TufDeck™ system. You’ll find detailed layouts for:

• The Cutting Deck: Every spindle assembly, high-lift blade, and idler pulley is indexed so you can see the exact assembly order.

• Hydrostatic Drive: The WB700’s twin-hydrostatic circuit is complex, but this guide breaks down the pumps, wheel motors, and lines with total clarity.

• Controls and Chassis: From the steering levers and throttle cables to the caster wheel forks and drive tires.

• Electrical and Safety: Full schematics for the wiring harness, ignition modules, and those essential safety interlock switches.

Built for the Field

Since this is a searchable PDF, you don’t have to flip through 300 pages to find a bolt. You can pull it up on your phone while you're standing over the machine, search for a keyword, and zoom in on the vector illustrations to see the smallest fasteners. It’s a practical resource for landscape pros and mechanics who need to stay "OEM-accurate" while keeping their gear in the dirt.
