Bobcat TR50210 Evo Telehandler Parts Catalog - PDF

Bobcat TR50210 Evo Telehandler | Parts Catalog

The Bobcat TR50210 Evo is a high-capacity powerhouse, blending the utility of a crane and an aerial platform with 360-degree rotation. To keep this 5.0-tonne lift capacity machine safe and operational, precision part identification is a must. This official catalog covers Serial Sequences BVL1550000 & Above and XVL1550000 & Above, providing the factory-authorized diagrams needed for professional maintenance.

Detailed System Identification

This manual offers deep visual clarity for the complex Evo-series assemblies, ensuring you source the correct hardware for:

• Rotation & Slew Group: Complete views of the slew ring bearings, rotary motors, turret base, and swivel joint seals.

• Multi-Stage Boom: Detailed layouts for the reinforced boom weldments, extension hardware, and specialized wear pad kits.

• Stabilizers & Outriggers: Comprehensive indexing of stabilizer legs, hydraulic cylinders, and leveling pad assemblies.

• Hydraulics & Electrical: Precise schematics for variable displacement pumps, Load Moment Indicators (LMI), rotation sensors, and the full Evo-series wiring harness.

Professional Digital Features

Delivered as a searchable PDF, this catalog is designed for immediate use. High-resolution vector illustrations allow you to zoom in on tiny hydraulic fittings or electrical pins without losing detail. Compatible with smartphones and tablets, it lets you verify part numbers right at the machine, eliminating ordering errors and ensuring every repair meets Bobcat's rigorous safety standards.
