Bobcat DT20 Dethatcher Parts Manual (SN B6FV & B6GB)

Maintaining the professional turf-care performance of your Bobcat DT20 starts with having the right data. This official parts catalog is the definitive visual guide for units starting with serial numbers B6FV11001 and B6GB11001. When we look at high-speed equipment like dethatchers, using exact OEM-matched hardware is the only way to ensure the blade velocity and stripping efficiency stay at factory standards.

This 322+ page digital resource provides clear, exploded views for every major system:

• Reel & Blades: Full flail blade assemblies, shafts, and high-speed bearings.

• Engine & Drive: Precise part numbers for drive belts, pulleys, and centrifugal clutches.

• Wheels & Axles: Height adjustment linkages and semi-pneumatic tire hardware.

• Controls: Depth adjustment knobs, bail levers, and throttle cables.

By using these factory-validated diagrams, you remove the risk of ordering incorrect belts or springs. The high-resolution vector illustrations allow you to zoom in on tiny bushings and washers while keeping the image crisp. Since this is an instant PDF download, you can search for part numbers on your phone or tablet while standing right in the shop. It is the most reliable way to maintain the heavy-duty steel chassis and precision linkages of your DT20 for years to come.
