Bobcat BCA24 Compactor Parts Manual Instant PDF

High-density soil compaction requires your equipment to handle intense vibration and high hydraulic pressure without failing. This official parts catalog for the Bobcat BCA24 compactor is your primary tool for keeping this attachment in peak condition. It covers serial numbers starting at 491911050 and includes the specific revisions made for the 491911099 and above production sequence. By using these factory-authorized exploded views, you can identify every internal component, from the heavy-duty bearings to the specialized isolation mounts.

Navigating repairs is straightforward thanks to a logically organized parts hierarchy. Whether you need to fix a leak in the high-pressure port manifolds or replace worn-out vibration-dampening bushings, this manual provides the exact OEM numbers you need. Using the correct hardware is vital to protecting both your attachment and your carrier machine from the stress of high-frequency centrifugal forces.

Key Visual Modules:

• Vibratory Housing: Eccentric shafts and sealed oil housing parts.

• Hydraulic System: Drive motor components and full seal kits.

• Mounting & Frame: Quick-attach plates and isolation rubber mounts.

• Hardware: High-tensile bolting and precision lock pins.

This 315-page PDF is fully searchable and bookmarked, allowing you to find specific part names in seconds. You can download it instantly and view the high-resolution illustrations on your phone or tablet while you are at the job site. This ensures you order the right hardware the first time, reducing downtime and extending the operational life of your compaction equipment.
